FRP Water Tank Quick details
Design pressure: 100 PSI, 150 PSI
Fatigue test: 100000 times.
Keywords:FRP pressure vessel,FRP water pressure tank(vessel),FRP tank
Burst test: 4 times of its design pressure.
Working temperature: 1 °C to 49 °C (34°F to 120°F).
Tanks with upper filling port/lower discharge port available.
OEM FRP tanks also available.
Food grade HDPE inner liner.
No leakage, stable pressure.
FRP Water Softener Product description
Water softener is a resin chemical base water treatment system which is used to make soft water by removing"hardness"from the raw water. The ”Hardness” means over containing of calcium and magnesium dissolves in to the raw water.It is designed according to the raw water quality and as per requirement of product water quality.It can be used alone or incorporate with reverse osmosis system.
Fiberglass FRP soft water tank application:
1.All feed water and waste water treatment application, included multi-media filter and softener.
2.Industrial Water Treatment with multi-layer media.
3. Water Softening.
4.Centralized Filtration System for high rise residential and commercial buildings such as residence , high rise office building, hotels and resorts.
5. Aquaculture, fish farming filtration system.
6.Many other water filtration and treatment applications.
7.Widely used in factory, Enterprises, government, hotel, motel, restaurant, residence as storage facility.
8.Used as equipment in drinking water treatment and fire water supply.
FRP Softener Tanks Specification | ||||
Item | Size | Dimensions | CBM | |
Dia.*Height | Model | m | ||
1 | 150*254 | 610-2.5" | 0.166*0.166*0.259 | 0.007137004 |
2 | 150*320 | 613-2.5" | 0.166*0.166*0.335 | 0.00923126 |
3 | 150*432 | 617-2.5" | 0.166*0.166*0.437 | 0.012041972 |
4 | 150*457 | 618-2.5" | 0.166*0.166*0.462 | 0.012730872 |
5 | 150*736 | 629-2.5" | 0.166*0.166*0.741 | 0.020418996 |
6 | 150*889 | 635-2.5" | 0.166*0.166*0.894 | 0.024635064 |
7 | 180*320 | 713-2.5" | 0.188*0.188*0.335 | 0.01184024 |
8 | 180*422 | 717-2.5" | 0.188*0.188*0.437 | 0.015445328 |
9 | 180*610 | 724-2.5" | 0.188*0.188*0.625 | 0.02209 |
10 | 180*762 | 730-2.5" | 0.188*0.188*0.777 | 0.027462288 |
11 | 180*879 | 735-2.5" | 0.188*0.188*0.894 | 0.031597536 |
12 | 180*1108 | 744-2.5" | 0.188*0.188*1.124 | 0.039726656 |
13 | 200*330 | 813-2.5" | 0.338*0.215*0.215 | 0.0156 |
14 | 200*432 | 817-2.5" | 0.437*0.215*0.215 | 0.0202 |
15 | 200*610 | 824-2.5" | 0.625*0.215*0.215 | 0.0289 |
16 | 200*890 | 835-2.5" | 0.895*0.215*0.215 | 0.0414 |
17 | 200*1120 | 844-2.5" | 1.125*0.215*0.215 | 0.0520 |
18 | 230*432 | 917-2.5" | 0.455*0.24*0.24 | 0.0262 |
19 | 230*890 | 935-2.5" | 0.9*0.24*0.24 | 0.0518 |
20 | 230*1068 | 942-2.5" | 1.073*0.24*0.24 | 0.0618 |
21 | 230*1220 | 948-2.5" | 1.225*0.24*0.24 | 0.0706 |
22 | 250*432 | 1017-2.5" | 0.429*0.266*0.266 | 0.0304 |
23 | 250*484 | 1019-2.5" | 0.494*0.266*0.266 | 0.0350 |
24 | 250*610 | 1024-2.5" | 0.622*0.266*0.266 | 0.0440 |
25 | 250*890 | 1035-2.5" | 0.886*0.266*0.266 | 0.0627 |
26 | 250*1119 | 1044-2.5" | 1.135*0.266*0.266 | 0.0803 |
27 | 250*1373 | 1054-2.5" | 1.38*0.266*0.266 | 0.0976 |
28 | 300*1220 | 1248-2.5" | 1.233*0.318*0.318 | 0.1247 |
29 | 300*1333 | 1252-2.5" | 1.333*0.318*0.318 | 0.1348 |
30 | 300*1652 | 1265-2.5" | 1.663*0.318*0.318 | 0.1682 |
31 | 330*1117 | 1344-2.5" | 1.1*0.343*0.343 | 0.1294 |
32 | 330*1372 | 1354-2.5" | 1.38*0.343*0.343 | 0.1624 |
33 | 350*1336 | 1452-2.5" | 1.336*0.369*0.369 | 0.1819 |
34 | 350*1336 | 1452-4" | 1.336*0.369*0.369 | 0.1819 |
35 | 350*1661 | 1465-2.5" | 1.661*0.369*0.369 | 0.2262 |
36 | 350*1661 | 1465-4" | 1.661*0.369*0.369 | 0.2262 |
37 | 350*1850 | 1465-4"-4" | 1.85*0.58*0.59 | 0.6331 |
38 | 400*1325 | 1652-2.5" | 1.325*0.428*0.428 | 0.2427 |
39 | 400*1325 | 1652-4" | 1.325*0.428*0.428 | 0.2427 |
40 | 400*1668 | 1665-2.5" | 1.668*0.428*0.428 | 0.3056 |
41 | 400*1668 | 1665-4" | 1.668*0.428*0.428 | 0.3056 |
42 | 400*1877 | 1665-4"-4" | 1.877*0.418*0.418 | 0.3280 |
43 | 450*920 | 1836-4" | 0.92*0.465*0.465 | 0.1989 |
44 | 450*1350 | 1853-4" | 1.35*0.465*0.465 | 0.2919 |
45 | 450*1655 | 1865-4" | 1.655*0.465*0.465 | 0.3579 |
46 | 450*1873 | 1865-4"-4" | 1.873*0.465*0.45 | 0.3919 |
47 | 500*1770 | 2069-4" | 1.77*0.512*0.512 | 0.4640 |
48 | 500*1955 | 2069-4"-4" | 1.955*0.512*0.512 | 0.5125 |
49 | 550*940 | 2136-4" | 0.94*0.543*0.543 | 0.2772 |
50 | 550*1370 | 2153-4" | 1.37*0.543*0.543 | 0.4039 |
51 | 550*1600 | 2162-4" | 1.6*0.543*0.543 | 0.4718 |
52 | 550*1804 | 2162-4"-4" | 1.804*0.543*0.543 | 0.5319 |
53 | 600*1920 | 2465-4"-4" | 1.92*0.614*0.6134 | 0.7231 |
54 | 600*2080 | 2472-4"-4" | 2.08*0.614*0.614 | 0.7842 |
55 | 750*1855 | 3065-4"-4" | 1.855*0.765*0.765 | 1.0856 |
56 | 750*2035 | 3072-4"-4" | 2.035*0.765*0.765 | 1.1909 |
57 | 750*2240 | 3072-6"-6" | 2.24*0.765*0.765 | 1.3109 |
58 | 900*1900 | 3665-4"-4" | 1.91*0.909*0.909 | 1.5782 |
59 | 900*2060 | 3672-4"-4" | 2.09*0.909*0.909 | 1.7269 |
60 | 900*2160 | 3672-6"-6" | 2.16*0.909*0.909 | 1.7848 |
61 | 1000*1940 | 4065-4"-4" | 1.95*1*1 | 1.9500 |
62 | 1000*1981 | 4065-6"-6" | 2.04*1*1 | 2.0400 |
63 | 1000*2160 | 4079-4"-4" | 2.29*1*1 | 2.2900 |
64 | 1000*2331 | 4079-6"-6" | 2.36*1*1 | 2.3600 |
65 | 1100*2180 | 4272-6"-6" | 2.18*1.07*1.07 | 2.4959 |
66 | 1200*2195 | 4872-6"-6" | 2.195*1.217*1.217 | 3.2510 |
67 | 1500*2425 | 6079-6"-6" | 2.25*1.5*1.5 | 5.0625 |
68 | 1600*2050 | 6367-6"-6" | 2.1*1.609*1.609 | 5.4367 |
69 | 1600*2460 | 6386-6"-6" | 2.6*1.609*1.609 | 6.7311 |
70 | 1800*2650 | 7279-6"-6" | 2.65*1.8*1.8 | 8.5860 |
71 | 2000*2600 | 8079-6"-6" | 2.60*2.036*2.036 | 10.7778 |
